Bootmod3 S63TU Tune – BMW M5 / M6 / X5M / X6M (F1x)

OVERVIEW

bootmod3 is the world’s first, most advanced and most widely adopted cloud-based flash tuning platform for BMW F and G series vehicles. It is a cloud solution with a web-based interface and native mobile apps for iOS and Android, developed and tested in-house from the ground up over almost two years before its November 2016 debut, with new features and updates added regularly.

This listing is the bootmod3 flash tuning license for the S63TU engine. Build the tune for your S63TU-powered vehicle and go from stock to full race calibration, and everywhere in between, with a map switch in the mobile app. bootmod3 calibrates the factory vehicle modules over the OBD port in a matter of minutes, in your own driveway or anywhere internet access is available.

SPECS

• Supported engine: BMW S63TU 4.4L twin-turbo V8
• Flashes the factory DME over the OBD port
• Stage 1, 91 octane: up to 16% HP / 26% TQ
• Stage 1, 93 octane: up to 18% HP / 28% TQ
• Stage 2, 91 octane: up to 20% HP / 30% TQ
• Stage 2, 93 octane: up to 22% HP / 31% TQ
• Stage 2, race gas: up to 26% HP / 31% TQ
• Stage 2 AGG (aggressive burble) versions of the maps are also available
• Ability to log any internal RAM variable value, with a number of presets available
• Cloud-based flash tuning platform; web interface at bootmod3.net plus native iOS and Android apps, with Windows and macOS support
• Flashes the factory DME through the OBD port — no module removal for OBD-supported vehicles
• Full map switching between stock, street and race calibrations from the app
• Return to stock supported — reverts the performance map and re-locks the DME to stock programming
• Datalogging of hundreds of diagnostic channels, up to 70+ concurrently, at the highest throughput and sample rates available
• Datalog sharing and charting in the app or web browser with no third-party upload required
• Cloud storage for map data and datalogs
• Live Dash — real-time vehicle parameter monitoring via in-app gauges
• Diagnostics: read and clear trouble codes in all vehicle modules
• Reset learned adaptations (octane, knock, Valvetronic and others)
• ECU power reset
• Full map editor included — tune the car yourself or with a tuner from the bootmod3 Tuner Directory
• OTS and custom map features available on this platform: map customization through the map editor, Max Cooling Mode, cold start (cat heating) removal for a quieter cold start, cat efficiency check (CEL) removal for de-cat downpipes (off-road use only), custom TMAP sensor adjustments, exhaust flap adjustments in Sport mode, top speed limiter removal, custom high-pressure fuel pump settings, boost-by-gear percentage reduction, DTC deactivation, re-calibrated sport gauges on iDrive, E85/blend, race gas and meth injection tuning, custom throttle mapping, and backend flash maps for piggyback use
• Optional off-the-shelf tunes for 91 / 93 / race gas / E85 are sold separately by bootmod3
• All sales are final on bootmod3 licensing

PARTS INCLUDED

• One bootmod3 S63TU flash tuning license, issued for a single vehicle. The license is tied to the VIN / DME it is activated against and is not transferable between vehicles.
• Access to the bootmod3 cloud platform, web interface and the iOS / Android apps for the licensed vehicle
• One off-the-shelf (OTS) map of your choice included with the purchase, plus any other maps labeled "FREE"
• Custom tuning support — the licensed vehicle can receive custom maps from any tuner in the bootmod3 Tuner Directory, and the built-in map editor is included
• Datalogging, Live Dash gauges, diagnostics and return-to-stock functionality for the licensed vehicle
• Activation link delivered by email within 12 hours of payment
• No physical hardware is shipped with the license itself. If you select the bundle option in the variant selector, a bootmod3 OBD WiFi Adapter ships with your order.

TECH RESOURCES

Additional Parts Required

• OBD-to-Ethernet (ENET) cable — required for laptop flashing. This is the generic cable also used for OEM BMW programming with factory software tools. Speed Logic does not currently stock this cable; source a standard OBD2-to-Ethernet BMW coding cable.
• bootmod3 OBD WiFi Adapter — optional alternative to a laptop, and available on this listing as a bundle option in the variant selector. It removes the need to use a laptop in the car. It is not required to use the bootmod3 platform.
• A compatible device — either a laptop running Windows or macOS with the Google Chrome browser, or an iOS / Android phone running the bootmod3 app.
• A USB-to-Ethernet adapter — only if your laptop has no built-in Ethernet port.
• Battery charger or maintainer — bootmod3 strongly recommends supporting the vehicle battery during flashing. Speed Logic does not stock chargers; use a unit rated for your battery type.
• Windows Defender, macOS firewall and any third-party antivirus or network protection must be disabled for the duration of the flash, and any piggyback device must be removed from the vehicle.

Installation

• bootmod3 — How to install bootmod3 on your vehicle (official bootmod3 wiki)
• bootmod3 — How to flash your BMW F and G series with bootmod3 (official bootmod3 wiki)
• bootmod3 v3.0 User Manual (official bootmod3 wiki)
• bootmod3 — OBD Agent instructions, laptop version (official bootmod3 wiki)
• bootmod3 — Flash failure troubleshooting: DME, TCU, online recode (official bootmod3 wiki)
• bootmod3 help center and full documentation index (official bootmod3 wiki)

Notes

• ** All purchases are final on bootmod3 licensing. **
• ** Activation link will be sent within 12hrs after payment has been received. **
• VEHICLE MANUFACTURER WARRANTY AND EMISSIONS DISCLAIMER
• Some items used and/or installed by SPEED LOGIC may void portions of your vehicle’s factory warranty. Some items may not be legal for “on highway use”. SPEED LOGIC makes no guarantees to the legality of any parts used for “on highway vehicles” and accepts no responsibility for compliance with the vehicle’s factory warranty.
• bootmod3 does not publish an official part number for this license and no SKU is recorded against this listing, so no part number is shown.
