Dinan Cold Air Intake – BMW 230i / 330i / 430i (F22/F23/F30/F31/F32/F33/F34/F36)

OVERVIEW

Following the path set by its six-cylinder counterpart, the Dinan cold air intake for the B46/B48 four-cylinder improves on the factory design with a larger, fully sealed airbox and a larger filter element, increasing flow, sharpening throttle response and reducing strain on the turbocharger. The factory intake tube carries internal baffling and a small Helmholtz chamber to suppress sound, and both create turbulence that costs power; Dinan developed a carbon fiber tube that removes those restrictions and lets the intake tract breathe. On an otherwise stock vehicle the finished system produces 6 HP and 6 lb-ft at 5000 RPM.

The intake is built entirely from carbon fiber rather than the mix of materials used on earlier four-cylinder kits, and the grade of material and its coating have both been improved over previous generations so the engine bay still presents well years later.

SPECS

• Max gains: +6 HP @ 5000 RPM and +6 lb-ft @ 5000 RPM on an otherwise stock vehicle (+5 WHP / +5 WTQ)
• Air box 30% larger than stock and fully sealed for maximum insulation from under-hood heat
• 34% increase in filter area — stock 76.3 in², Dinan 102.1 in²
• Optimized carbon fiber intake tube with the factory baffling and Helmholtz chamber removed
• Full carbon fiber construction, improved material grade and coating over previous-generation Dinan four-cylinder intakes
• Free-flowing injection-molded air mass meter housing, over 20% larger than stock
• Emissions, per Dinan: legal under the provisions of EPA’s Tampering Policy dated November 23, 2020. This product is NOT LEGAL FOR SALE OR USE IN THE STATE OF CALIFORNIA — CARB testing is pending, and no Executive Order number has been issued (Dinan Emission Code 7).
• Dinan warranty: if the vehicle is still covered by the BMW new-car limited warranty, the part is warranted for the remainder of that coverage, limited to 4 years / 50,000 miles; otherwise 2 years, unlimited mileage from the date of original purchase. Wear items, maintenance parts and fluids are excluded.

PARTS INCLUDED

• 1x Airbox lid (D762-0213-G)
• 1x Air flow meter (D762-0214)
• 1x Intake tube (D762-0218-G)
• 1x Silicone hose, air flow meter (D340-0433)
• 1x Silicone hose, turbo inlet (D340-0432)
• 1x Air filter (D401-0025)
• 1x Hardware kit (D763-0094)

TECH RESOURCES

Additional Parts Required

• None. Dinan specifies no additional hardware for this part — the kit is a bolt-on and includes its own air flow meter housing and hardware.
• Customer-supplied hand tools only; no tune is required.

Installation

• Dinan D760-0048 Cold Air Intake — installation instructions (PDF)

Notes

• Dinan’s installation instructions also list the F34 330i xDrive Gran Turismo. Dinan does not publish an engine code for that application — confirm fitment with Speed Logic before ordering.

PART NUMBER

• D760-0048

VEHICLE APPLICATIONS
