MHD Super License – BMW N13

OVERVIEW

The MHD Flasher F+G Series is a complete flash tuning application for your BMW N13. Unlike a piggyback module it performs full DME remapping while retaining all OEM safety mechanisms, which allows for maximum performance, maximum safety and unrivaled drivability.

You can install MHD at home and start tuning immediately. Download the MHD Flasher F+G Series app, connect the MHD wireless adapter to your vehicle's OBD-II port and pair it to your Apple iOS or Android device, then start the app — the initial installation completes within about 5 minutes, and further map changes take only about 30 seconds. You can return the vehicle to the factory OEM flash at any point, and no initial backup is required.

The Super License bundles every MHD function in one package: the Flasher license, the Monitor (datalogging and gauge) license and the N13 map pack.

SPECS

General

• Engine: BMW N13 1.6L Turbo I4, F Series
• ECU: Bosch DME, flashed over OBD-II — full remap, not a piggyback
• Flash time: approx. 5 minutes initial install, 30 seconds per map switch
• Stage 0: stock power, with all flash options available
• MHD+ map switching is not available for OTS maps on N13 — custom tune only.
• Supported devices: Apple iOS 10.2 and higher, Android 6 and higher

Off-the-shelf maps (road and dyno tested)

• Stock: 102–177 HP depending on model
• Stage 1 (stock cars): up to 200 HP / 280 Nm
• Stage 2 (high-flow downpipe and upgraded intercooler required): up to 235 HP / 350 Nm
• Octane variants: each stage is offered for 91 oct / 95 RON, 93 oct / 98 RON and 95 oct / 102 RON

Flash options

• Exhaust burble (duration in base and sport mode, aggressiveness, minimum speed, minimum RPM)
• Startup roar
• Cold start noise reduction
• Exhaust flap always open in sport mode
• Top speed limiter (Vmax) removal
• Sport / racing cooling mode for coolant
• Power limiting per gear
• Support for the XDI HPFP

Monitor and diagnostics

• Configurable gauge layout with up to 8 fully adjustable gauges
• 50+ engine parameters available at a glance and logged in the background
• Datalogging to standard CSV files with a built-in log viewer; free log analysis offered by MHD
• Available monitors include boost, boost target, lambda (AFR), intake air temp, ignition timing per cylinder, coolant temp, oil temp, oil pressure, transmission temp, HPFP, throttle position, wastegate duty cycle, RPM, speed and EGT
• Advanced parameters not exposed by BMW, such as timing corrections per cylinder, boost setpoint and active torque limiter (availability depends on DME software version if the car is not flashed with MHD)
• Read / delete engine fault codes and reset adaptations
• Return to the factory OEM flash at any time; no initial backup required
• Custom tuner maps and JB4 backend maps can be loaded in addition to the MHD OTS maps

PARTS INCLUDED

• One MHD Super License activation code, delivered by e-mail within 12 hours of payment
• License is issued against a single vehicle VIN and your MHD account e-mail, and is not transferable to another car, owner or account
• Flasher license (MHD OTS maps, JB4 backend maps and custom tuner maps)
• Monitor license (gauges, 50+ live parameters, CSV datalogging and log viewer)
• MHD N13 map pack
• Free MHD app download from the Apple App Store or Google Play
• No hardware is included with the license-only variant. The bundle variant on this listing adds the MHD Universal WiFi adapter.

TECH RESOURCES

Additional Parts Required

• MHD Universal WIFI Adapter — required to flash. The license is software only; you must have a supported interface to connect the app to the car. Not included with the license-only variant of this listing.
• Alternative supported interface if you already own one: ENET cable plus a Lightning adapter (iOS only), or K-DCAN cable plus an OTG adapter (Android only). MHD recommends its own WiFi adapter and cannot support third-party hardware.
• An Apple iOS 10.2+ or Android 6+ mobile device running the free MHD Flasher app — supplied by the customer.
• A free MHD account. Give us the account e-mail and the vehicle VIN at checkout; the license is bound to both.
• A battery charger or maintainer. MHD states a charger is highly recommended for the initial full write (install and uninstall) and for long writes on slower adapters.

Installation

• Step-by-step guide to setup, flashing, datalogging and returning to stock: Speed Logic MHD Tuning Guide (it links to every section of MHD's own user guide)
• Installation is performed by the customer through the MHD app over the OBD-II port; no workshop fitment is required.

Notes

• All purchases are final. MHD licenses are non-refundable and non-transferable.
• Your activation code is e-mailed within 12 hours of payment.
• Each license is tied to one vehicle VIN and one MHD account e-mail. A different car or account needs a new license.
• MHD+ map switching isn't available on N13 off-the-shelf maps — custom tunes only.
• For off-road use only.
• Not sure? Send us your VIN and we'll confirm fitment and any unlock needs before you order.

VEHICLE APPLICATIONS

These models were not sold in the US. Years are production years for the markets where they were sold. MHD lists 2012–2018 for the 316i; the N13 316i was replaced by the B38-engined 316i around 2015, so later 316i cars are not N13 and are not covered by this license. Engine changeovers follow the production date, so confirm your engine by VIN with Speed Logic before ordering.
