Bootmod3 B58 Tune – Toyota GR Supra Mk5 (A90 / A91)

OVERVIEW

bootmod3 (BM3) is a cloud-based flash tuning platform for the BMW F and G series and the 2020+ Toyota Supra. It is not a piggyback module — it writes a full calibration to the factory DME over the OBD port, and it has been developed and tested in-house since its debut in November 2016, with new features and updates added regularly.

Everything is driven from a web interface for Windows and macOS, or from the bootmod3 mobile apps for iOS and Android. Build the tune for your A90/A91 Supra and move from stock to full race calibration — and everywhere in between — with a map switch in the app. Flashing takes a matter of minutes and can be done in your own driveway anywhere internet access is available.

This listing is a software license for one vehicle. It is not a physical part. An activation link is emailed to you after payment.

SPECS

• Platform: cloud-based full DME flash tuning for the B58 engine in the A90/A91 Toyota Supra
• Apps: iOS, Android, and web browser (Windows and macOS supported)
• Stage 1, 91 octane: up to 22% HP / 25% TQ
• Stage 1, 93 octane: up to 25% HP / 25% TQ
• Stage 1, E30: up to 28% HP / 27% TQ
• Stage 2, 91 octane: up to 26% HP / 28% TQ
• Stage 2, 93 octane: up to 28% HP / 28% TQ
• Stage 2, E30: up to 34% HP / 30% TQ
• Stage 2 AGG (aggressive burble) versions of the maps are also available
• Flash time: minutes, over the vehicle OBD port
• Return to stock: supported — reverts to the stock performance map and re-locks the DME to stock programming
• Custom tuning: full in-app map editor; custom tunes available through tuners in the bootmod3 Tuner Directory
• Datalogging: hundreds of diagnostic channels, up to 70+ channels concurrently
• Datalog sharing and charting in the app or web browser, with no third-party upload required
• Ability to log any internal RAM variable, with a number of presets available
• Cloud storage for map data and datalogs
• Live Dash: real-time vehicle parameter monitoring via in-app gauges
• Diagnostics: read and clear trouble codes in all vehicle modules
• Reset learned adaptations (octane, knock, Valvetronic and others)
• ECU power reset
• CustomROM and OTS map options available (including for upgraded turbo builds):
  • Map customization through the map editor
  • Exhaust burble adjustment on any map, OTS or custom
  • GTS startup roar
  • Max cooling mode
  • Cold start (cat heating on startup) removal for a quieter cold start
  • Cat efficiency check (CEL) removal for de-cat downpipes — off-road use only
  • Exhaust flap adjustment (Sport mode)
  • Top speed limiter removal
  • Exhaust OPF/PPF/GPF removal
  • Boost by gear % reduction
  • DTC deactivation
  • Re-calibrated sport gauges on iDrive
  • E85/blend, race gas and meth injection tuning
  • Custom throttle mapping
  • Backend flash maps for piggyback use

PARTS INCLUDED

• One bootmod3 software license, activated to a single vehicle DME. License transfers are handled by Bootmod3 — contact Speed Logic before purchase if the car may change hands.
• Activation link emailed within 12hrs of payment
• One OTS map/tune of your choice, plus any other maps labeled “FREE”
• Access to the bootmod3 mobile apps and web platform, cloud map/datalog storage, datalogging, Live Dash gauges and diagnostics
• Access to the full map editor and the bootmod3 Tuner Directory for custom tuning (custom tune fees are charged by the tuner, not included)
• Additional off-the-shelf maps for 91/93/race gas/E85 are a separate purchase from Bootmod3 unless labeled FREE
• No hardware is included with the license on its own. The bundle option in the variant selector above adds the bootmod3 OBD WiFi adapter.

TECH RESOURCES

Additional Parts Required

• ECU Unlock Service for BMW B58 Engines — 2020 Supra models running the November 2019 or later software update require a bench unlock before the DME can be flashed over OBD. Confirm your software level with Speed Logic before ordering.
• bootmod3 OBD WiFi adapter, or a generic OBD2-to-Ethernet (ENET) cable — one or the other is required to connect the car to bootmod3. Speed Logic does not stock these as separate listings; the WiFi adapter can be added using the bundle option in the variant selector above.
• A compatible device — an iOS or Android phone when using the WiFi adapter, or a Windows/macOS laptop (Google Chrome recommended) when using an ENET cable.
• Ethernet-to-USB adapter — only if your laptop has no built-in Ethernet port.
• Internet access at the vehicle — bootmod3 is a cloud platform and must reach the bootmod3 servers to download and flash a map.
• Battery charger or tender, recommended to hold voltage steady for the duration of the flash. Bootmod3 does not publish a minimum voltage figure; this is standard practice for any DME flash.

Installation

• How to install bootmod3 on your vehicle — official bootmod3 setup guide
• bootmod3 v3.0 User Manual
• bootmod3 Frequently Asked Questions
• Bootmod3 does not publish a printable installation PDF for this license; the manufacturer guides above are the current documentation.

Notes

• ** ALL PURCHASES ARE FINAL ON BOOTMOD3 LICENSING **
• ** Activation link will be sent within 12hrs after payment has been received **
• VEHICLE MANUFACTURER WARRANTY AND EMISSIONS DISCLAIMER: Some items sold and/or installed by SPEED LOGIC may void portions of your vehicle’s factory warranty. Some items may not be legal for “on highway use”. SPEED LOGIC makes no guarantees to the legality of any parts used for “on highway vehicles” and accepts no responsibility for compliance with the vehicle’s factory warranty.
• Bootmod3 does not publish an official part number for this license, so no part number is listed. If your B58 vehicle is not shown above, contact Speed Logic to confirm coverage before ordering.
